PA6-(GF+MD)40

40% Glass Fiber and Mineral Filled Nylon 6 (PA6-(GF+MD)40)

Product Overview

40% Glass Fiber and Mineral Filled Nylon 6 (PA6-(GF+MD)40) offers enhanced mechanical strength and thermal performance by combining high glass fiber content with mineral fillers. This compound excels in stiffness, dimensional stability, and creep resistance, making it an excellent choice for demanding structural applications.

The 40% glass fiber and mineral filler combination improves heat deflection temperature, reduces shrinkage, and enhances surface appearance. With reduced moisture absorption compared to unreinforced nylon, it ensures consistent performance in humid and high-stress environments.

Technical Specifications

• Material: Nylon 6 (Polyamide 6)

• Reinforcement: 40% Glass Fiber and Mineral Fillers

• Tensile Strength: 163 MPa

• Elongation at Break: 3%

• Impact Strength (23°C): 73 kJ/m²

• Specific Gravity/Density: 1.46 g/cm³

• Melting Point: 230°C

• Colors: Natural, Black, or Custom Colors

Application Scenarios

40% Glass Fiber and Mineral Filled Nylon 6 is ideal for applications requiring superior mechanical and thermal properties:

• Consumer Goods: Reinforced chair legs, luggage frames, and durable furniture brackets.

• Sports Equipment: Bicycle frames, pedals, and fitness equipment components demanding high stiffness.

• Renewable Energy: Frames and brackets for solar panels requiring dimensional stability and weather resistance.

• Infrastructure: Durable housings for electrical enclosures and construction tools.

Comparison with Other Glass Fiber and Mineral Filled Nylon Products

Applications

40% Glass Fiber and Mineral Filled Nylon 6 is commonly used in consumer goods, sports equipment, renewable energy, infrastructure, and structural applications requiring high strength, dimensional stability, and heat resistance.
